Sandtoft Calderdale Edge & TLE

Name: Sandtoft Calderdale Edge & TLE
Brand: Wienerberger

Large-format interlocking concrete tiles — the flat-profile Calderdale Edge and the through-coloured TLE, laid at around ten to the square metre. Fewer, larger tiles is the single biggest lever on a tiled roof’s carbon: about 9.5 kgCO₂e/m² against roughly 20 for the small-format plain tile off the same site.

Manufacturer page

Carbon and evidence

Product Evidence

Evidence currently held for the Wienerberger product record.

Wienerberger

Recorded Carbon Result

168kgCO₂e/t

A1–A3 GWP-total per tonne, as declared. GWP-fossil for the same stage is 207 kgCO2e/t — the gap is timber-pallet biogenic carbon booked in A3 and released in A5, a packaging artefact rather than a property of the tile, and it is the figure Wienerberger themselves publish. Both are stored. On the manufacturer's own conversion this tile is about 9.5 kgCO₂e per m² of roof (GWP-fossil basis, manufacturer-published rather than part of the verified declaration).

Indicator: GWP-total

Sandtoft Calderdale Edge & TLE — Sandtoft production line S6 (HUB-4622)

A1–A3 covers raw-material supply, transport to manufacture and manufacturing. It is product-stage information, not a whole-life result.

Environmental Product Declaration

EPD recorded

Coverage: Product family
Declared unit: 1 tonne (declared unit mass 1000 kg)
Programme: EPD Hub
Registration: HUB-4622
Standard: EN 15804:2012+A2:2019/AC:2021, ISO 14025
Valid until: 2031-01-18
Verification: Third-party verified

Keyed on the Sandtoft production line S6 rather than on a single product — it covers Calderdale Edge, Dual Calderdale Edge, Dual TLE and TLE. Manufactured to BS EN 490, data year 2022. Average tile weight 4.88 kg.

Read the EPDSource: Core environmental impact indicators table, A1-A3 column

Reported GWP Modules

Displayed as stored; modules are not added together here.

A1–A3

168 kgCO₂e

per 1 tonne of tile

* A4/A5 are EPD scenarios, not project-specific results. Module nomenclature follows BS EN 15978 / EN 15804. Declared values are suitable as inputs to a whole life carbon assessment under the RICS Professional Standard (2nd edition); this panel is not an assessment.

Service Life — the B4 Replacement Input

70 years · EPD reference service life

The declaration states a 70-year reference service life.

≈1 installation over a 60-year building study period.

B4 (replacement) follows the building, not the product: an assessor multiplies replacement cycles by project quantities. This record supplies the service life and does not compute B4.

Sourced Product Claims

About 9.5 kgCO2e/m² of roof at large format — tile format drives roof carbon more than material doesManufacturer declaredSource
Third-party verified EPD, valid to 2031-01-18Third-party verifiedSource

Evidence Sources

Sandtoft Calderdale Edge & TLE — Sandtoft production line S6 (HUB-4622)

EPD Hub

Third-party verified

Wienerberger Tile Production EPD Summary Document

Wienerberger

Manufacturer declared

Comparison Status

This result should be displayed for information only and not ranked against another product.

• The EPD is not linked to an evidence source.

Design & Specification Notes

Qualitative notes for early design discussion. Not product-specific EPD evidence, and not a basis for numerical comparison.

Large-format interlocking concrete tiles — the flat-profile Calderdale Edge and the through-coloured TLE, laid at around ten to the square metre.

Typical Uses

•Roof coverings
•Waterproofing layer
•Weather protection

Key Performance

High durability in wet exposure and wind uplift.

Specification Actions

•Specify GGBS/PFA cement replacement (target: 50%+ replacement).
•Request EPD showing embodied carbon per m3.
•Calculate transport distances for primary materials.

Indicative Health & Indoor Air

low Risk

Evidence:Third-party verified

Specification

Range: Sandtoft
Finish: Concrete roof tile, large format
Service life: 70 years
Country of manufacture: United Kingdom
