MOEDING Alphaton

Name: MOEDING Alphaton
Brand: MOEDING

Extruded terracotta rainscreen panel at 52.95 kg/m², the heavier of the two MOEDING systems. It shares a declaration with Longoton; the difference between them tracks their mass almost exactly.

Manufacturer page

Carbon and evidence

Product Evidence

Evidence currently held for the MOEDING product record.

MOEDING

Recorded Carbon Result

43.46kgCO₂e/m²

A1–A3 GWP-total per 1 m² of ceramic façade, Alphaton, 52.95 kg/m², as declared in EPD-MFA-GB-48.0. Module D (-5.45) is excluded.

Indicator: GWP-total

MOEDING Alphaton Environmental Product Declaration · EPD-MFA-GB-48.0, p. 15, "Results per 1 m² of Alphaton ceramic façade", GWP-t row, A1-A3 column (read from a 130 dpi render)

A1–A3 covers raw-material supply, transport to manufacture and manufacturing. It is product-stage information, not a whole-life result.

Environmental Product Declaration

EPD recorded

Coverage: Product family
Declared unit: 1 m² of ceramic façade, Alphaton, 52.95 kg/m²
Programme: ift Rosenheim GmbH (German Type III / ECO Platform operator — NOT IBU)
Registration: EPD-MFA-GB-48.0
Standard: EN 15804+A2
Valid until: 2027-10-17
Verification: Third-party verified

Shares one declaration with MOEDING Longoton (46.76 kg/m², 37.76 kgCO2e/m²), which is held as a separate record. The reference element size for Alphaton is 6.00 m x 6.80 m.

Read the EPDSource: EPD-MFA-GB-48.0, p. 15, "Results per 1 m² of Alphaton ceramic façade", GWP-t row, A1-A3 column (read from a 130 dpi render)

Reported GWP Modules

Displayed as stored; modules are not added together here.

A1–A3

43.5 kgCO₂e

per 1 m² of ceramic façade, Alphaton, 52.95 kg/m²

* A4/A5 are EPD scenarios, not project-specific results. Module nomenclature follows BS EN 15978 / EN 15804. Declared values are suitable as inputs to a whole life carbon assessment under the RICS Professional Standard (2nd edition); this panel is not an assessment.

Sourced Product Claims

Third-party verified EPD (EPD-MFA-GB-48.0)Third-party verifiedSource

Evidence Sources

MOEDING Alphaton Environmental Product Declaration

ift Rosenheim GmbH (German Type III / ECO Platform operator — NOT IBU) · EPD-MFA-GB-48.0, p. 15, "Results per 1 m² of Alphaton ceramic façade", GWP-t row, A1-A3 column (read from a 130 dpi render)

Coverage: Shares one declaration with MOEDING Longoton (46.76 kg/m², 37.76 kgCO2e/m²), which is held as a separate record. The reference element size for Alphaton is 6.00 m x 6.80 m.

Third-party verified

Comparison Status

This result should be displayed for information only and not ranked against another product.

• The PCR and version are missing.

Design & Specification Notes

Qualitative notes for early design discussion. Not product-specific EPD evidence, and not a basis for numerical comparison.

Extruded terracotta rainscreen panel at 52.

Typical Uses

•Facade cladding
•Weather protection
•External accents

Key Performance

Weather-resistant finish for facade exposure.

Typical Service-Life Estimate

40 years

Generic estimate for early design discussion; confirm with the manufacturer.

Specification Actions

•Confirm the current EPD covers the selected product, finish and manufacturing route.
•Calculate transport distances for primary materials.
•Document material reuse or reclaimed content percentages.

Indicative Health & Indoor Air

low Risk

Evidence:Third-party verified

Specification

Range: Alphaton
Finish: Terracotta rainscreen facade panel
