Kingspan QuadCore Insulated Panel
Structural insulated cladding and roofing panel — twin coated-steel facings bonded to Kingspan’s QuadCore hybrid insulation core, forming a single-component building envelope with high thermal performance and fast dry installation. Wide range of profiles and coating colours for walls and roofs.
Carbon and evidence
Product Evidence
Evidence currently held for the Kingspan product record.
Recorded Carbon Result
A1–A3 GWP-total per m² of 100 mm panel, per EPD
A1–A3 covers raw-material supply, transport to manufacture and manufacturing. It is product-stage information, not a whole-life result.
Environmental Product Declaration
EPD recorded- Coverage
- Representative product
- Declared unit
- 1 m² panel, 100 mm (37 kg/m³ core)
- Programme
- Instytut Techniki Budowlanej (ITB) — Eco Platform
- Registration
- No. 552/2023
- Standard
- EN 15804+A2
- Valid until
- 2028-12-12
- Verification
- Third-party verified
Third-party verified (ITB / ECO Platform). Figure is for the 100 mm panel; the EPD tabulates 40–200 mm and impact scales with thickness. Module D (−37.7) is large because the coated-steel facings are recyclable — the recovery credit exceeds the product-stage carbon.
Carbon profile
kgCO2e per 1 m² panel @100mm · each bar starts at zero · local scale
A1-A3 product
28.4
A4-A5 site*
—
B use
—
C end of life
6.2
D reuse / recycling
-37.7
Reported GWP Modules
Displayed as stored; modules are not added together here.
A1–A3
28.4 kgCO₂e
per 1 m² panel @100mm
C1
0.0286 kgCO₂e
per 1 m² panel @100mm
C2
0.107 kgCO₂e
per 1 m² panel @100mm
C3
6.05 kgCO₂e
per 1 m² panel @100mm
C4
0.0124 kgCO₂e
per 1 m² panel @100mm
D
-37.7 kgCO₂e
per 1 m² panel @100mm
Service Life — the B4 Replacement Input
50 years · EPD reference service life
≈2 installations over a 60-year building study period.
2 claims and 1 certification are held in the staging record but not presented as product evidence because an exact public source has not yet been mapped.
Comparison Status
This result should be displayed for information only and not ranked against another product.
- • The PCR and version are missing.
- • The GWP indicator is missing.
- • The carbon result is not linked to an evidence source.
- • The EPD is not linked to an evidence source.
Evidence Gaps
- •2 sustainability claims are withheld because exact public evidence is not mapped.
- •1 certification is withheld because exact public evidence is not mapped.
Design & Specification Notes
Qualitative notes for early design discussion. Not product-specific EPD evidence, and not a basis for numerical comparison.
Structural insulated cladding and roofing panel — twin coated-steel facings bonded to Kingspan’s QuadCore hybrid insulation core, forming a single-component building envelope with high thermal performance and fast dry installation.
Typical Uses
- •Facade cladding
- •Weather protection
- •External accents
Key Performance
Weather-resistant finish for facade exposure.
Specification Actions
- •Confirm the current EPD covers the selected product, finish and manufacturing route.
- •Calculate transport distances for primary materials.
- •Document material reuse or reclaimed content percentages.
Indicative Health & Indoor Air
Factory-made insulated panel; inert in use.
Specification
- Range
- Metal-faced insulated panels (wall & roof)
- Collection
- QuadCore
- Finish
- Metal-faced PIR insulated panel
- Thickness
- 40–200mm
- Service life
- 50 years
